Liteharbor Lighting – Leading Fire Rated Slim Panel Manufacturers and Factory in China, Focus on Fire Rated Slim Panel, Recessed Lighting, Fire Rated Downlight, Professional Fire Rated Lighting OEM, ODM and Fire Rated Lighting Solutions. More Fire Rated Slim Panel Products >>

Fire Rated Slim Panel Features

The PRISA Fire Rated series passed fire rated in UL 263 tested comes with a Certified 2-Hour Fire Rating back plate which provides a reinforced and heat resistant casing for up to 2 hours of protection . This unique design and technology has been patented and offers an affordable solution in applications.

2 Hour Fire Rated: Without additional housing or hardware
Installation Dimension: Available in all standard 4″ round openings
Heat Resistant Casing: Provides up to 2 hours fire protection
Heavy Duty Steel Spring: Clips for easy installation
Plenum Rated Cable: For commercial installations
Connection Box: Comes with Junction Box & Driver,No Housing Required.
1/2″ Thin: Install Directly Under Joists, Maximum Layout Flexibility
CRI : 80+, 90+ True color rendering
CCT: 3CCT range changeablen,3000K, 4000K and 5000K
5CCT range changeablen,3000K,3500K,4000K,4500K,5000K

Trim with powder paint coat preventing discoloring and rusting. Available in several finishes in a variety painted trim options, and available in different colors finishes.

The box includes a Commercial Grade Driver designed for 24-hour usage. It is constructed of aluminum extrusion, with knockouts located at each end. Wiring compartment allows for (6) 14 gauge (AWG) insulated conductors. Connection to one (1) downstream unit is permitted within the junction box compartment.

LED quickly connector for shallow ceiling installations with no housing required. Installed with Heavy-Duty Commercial Grade Steel spring clip, to withstand excessive heat. The clips allow for easy installation.

Plenum rated cable used to connect light unit and junction box.

DIRECT or EDGE-lit LED technology uses light guided plate to distribute light. A polycarbonate lens is used to provide even illumination throughout the installation. The regressed design offers an anti-glare feature.

Easily connected to a 120V power supply via provided UL recognized driver. Dimming down to 10% with most standard LED dimmers (see list of approved dimmers). Ambient operating temperature: -40°C (-40°F) to +40°C (+104°F).

This product is ETL listed in USA & Canada. It has been tested for a 2-HOUR FIRE RATING and complies with ASTM E283/283M-19, UL 263 and certified to UL standard 1598 and CSA standard C22.2#250.0:2021. The PRISA Fire rated series meets the 2-hour rating with most floor-ceiling assemblies includingfollowing: UL L505, L511, L536, L538, L541, L556, L577, M500, M510, M521 and M543. Energy start testings passted complies with V2.2 SSL.

Fire Rated Slim Panel Specification









Energy Used

9 W



Light Output (lm)




Lumen/ Watt


Color Temperature (K)

2700K – 3000K – 3500K – 4000K – 5000K-6000K,
3CCT, 5CCT, Warm Dim, Tunable White

Halogen Equivalent

LED 1W= Halogen 6W

Beam Angle




Driver Input

120V AC 50/60 Hz


TRIAC Dimmers 10% – 100%

Approved Location

Insulated Ceiling & Damp Locations


FT6 / CMP Plenum Rated

Air Tight



White,Black,Satin Nickel

Ambient Temperature

-4°F (-20°C) to +104°F (+40°C)

Projected Life

70% Light Output at 50,000 Hours



Fire Rating

UL 263-2011(R2022), STM E119-20 & CAN/ULC-S101-14


5 Year

Fire Rated Slim Panel Lighting FAQ

Fire rated downlights are lighting fixtures that have been designed and tested to resist the spread of fire in ceilings or walls. They typically feature a fire-resistant casing or cover, as well as intumescent material that expands when exposed to heat to seal off gaps and prevent flames from spreading. Fire rated downlights are commonly used in commercial and residential buildings to meet fire safety regulations and protect against potential hazards.

Fire-rated lighting standards typically require that the light fitting maintains its structural integrity and fire resistance for a specified period, usually 30, 60, or 90 minutes, in the event of a fire. The standards also specify the type of materials and construction methods that must be used for the light fitting to meet the required level of fire resistance. Additionally, fire-rated lighting may need to comply with other relevant standards, such as those related to electrical safety and energy efficiency.

One way to spot fake or shoddy fireproof downlights is to look for certification markings from recognized organizations such as UL or ETL, which test and certify products for safety. It’s also important to purchase from reputable sellers and avoid suspiciously low-priced items, as these may indicate a lower quality or unsafe product. Fre rated recessed downlights can close off the ceiling cutout hole and slow down the spread of fire in the event of a fire, compared to traditional downlights. They effectively block the hole cut into the ceiling. On each downlight they have an Fireproof Cotton is activated at temperatures above 190°C and unidirectional expansion the 5 times soon, to prevent fire and smoke spread to other parts of the building, and ultimately slow the spread of fire. Different fire rated downlights have different fire rated times, varying for 30, 60, 90 and 120 minutes.
