Lighting Project 6″ Architectural Square LED Commercial Downlights Manufacturer

Features

Architectural LED luminaire, iron shell spray production, with anti-corrosion shell. Emergency system is available.

Isolated power supply, safe and without flicker.

LED light source using high quality, high lumen and high CRI LED bead.

Square emitting surface, with uniform light distribution, high luminous efficiency. Energy saving, long lifespan even without maintain.

New generation of cold light source, save power, excellent casting performance with far and high light casting compare to common fluorescent and energy saving lamp

Specification

Power 35W max
Voltage 120V/277V/120-277V
Lumen 3000/2500 LM
Power factor PF>0.98
CRI 80+/90+
Beam angle 60°, 90° optional
Dimmable NONE/0 ~ 10v dimming
CCT 2700K/3000K/4000K/5000K/6000K
Certification ETL
Lifespan 50000H



Lampshade

Aluminum fog reflective reflector, high light uniformity.

With marbles design mode, the overall height of the size is controlled, smooth appearance, excellent visual effects.

Light Source\ Radiator

High light transmittance, strong light diffusion performance, no shadow no glare.

Point light source emitting turned into spherical light emitting.

Milky white light transmission rate reach 90% above.

Excellent concealed light source, achieve the best light transmission rate without seeing the LED lamp bead.

Outstanding heat dissipation aluminum material, the temperature is guaranteed to be the touch temperature below.

Locating Part

Locating part, easy for installation,will not cause abnormal phenomena such as deformation. Resolved the problem of product is not centered.

Application

Warehouse, office, hallway.

Packing

Outer box:48×44.5×19CM   2pcs/CTN
U type staddle outer box: 65.5*16.6*5CM  10pcs/CTN
